 Features
| PRODUCT FEATURES | | > Stylish appearance with nVIDIA logo | | > Accommodates up to six 120 mm fans for high-efficiency ventilation | | > Removable HDD racks provide for easy assembly | | > Cable management design for better cable routing and neatness | | > Tool-free user-friendliness for quick maintenance and upgrade | | > nVIDIA SLI cerified chassis | | | | PRODUCT HIGHLIGHTS | | Tool-free Mechanism |
|  | > Removable HDD racks with anti-vibration pads for easy assembly and reduced noice |
|  | > Tool-free kits for add-on card installation |
|  | > Tool-free design for 5.25" devices |
|  | > Thumb-screws for easy open side panel |
Specifications
| Model |
NV-690C-KWN2-GP |
|
| Available Color |
Black |
|
| Dimension |
(L)524.5 X (W)213 X (H)482 mm |
|
| Material |
Chassis: SECC, Bezel: Metal mesh+ABS |
|
| Motherboards |
ATX, Micro-ATX |
|
| 5.25" Drive Bay |
5 Exposed (without the use of exposed 3.5” drive bay) |
|
| 3.5" Drive Bay |
1 Exposed (converted from one 5.25” drive bay) |
|
| HDD Support |
5 |
|
| Cooling System |
Front :120 mm green LED fan x 1, 1200 rpm, 21 dBA, Rear : 120 mm standard fan, 1200 rpm, 21 dBA Top : 120 or 140 mm fan x 2 (optional) Bottom : 120 mm fan x 1 (optional) Left : 120 mm standard fan x 1 Right : one 80 x 15 mm fan (optional) |
|
| I/O Panel |
USB 2.0x2, IEEE 1394 x1, MIC x1, eSATA x 1, SPK x1 (support Intel HD /AC’ 97 Audio) |
|
| Expansion Slots |
7 |
|
| Power Supply |
Standard ATX PS2/ EPS 12V (Optional) |
|
Gallery
Disclaimer: Images are for informative purposes only; displayed parts and accessories may not be included in the actual product package.
|
|
"Overall, the Cooler Master NV690 is a good case at a good price. It looks
excellent, and with the right lighting scheme would really draw the eye. It has
many features that are not commonly found on a mid-tower chassis, and the price
is more than fair."
» Details
|
BMR - Golden Tachometer
|
|
"I would definitely recommend this enclosure
especially for those on a budget. The price isn't much higher than cases that
have no real cooling options or tool less features. Other cases try to get your
attention with silly lights and cheesy side windows, but still have a very
generic and cheap look. The NV 690 NVIDIA edition makes a bit of a statement
without a total generic look while providing good "out of the box"
performance.The fans that are included are very quiet while providing decent
airflow."
» Details
|
Download |
|
FAQ |
| There are no FAQ items for this product |
|
More Information |
|
There are no extra information for this product |
